Definitions
1 Choke Knob
Eases engine starting by enriching
mixture.
2 Carburetor Adjusting Screws
For tuning the carburetor.
3 Spark Plug Boot
Connects the spark plug with the
ignition lead.
4 Air Filter Cover
Covers and protects the air filter
element.
5 Stop Switch
Switches the engine´s ignition off
and stops the engine.
6 Throttle Trigger Lockout
Must be depressed before the
throttle trigger can be activated.
7 Control Handle
For holding and controlling the unit
with the right hand during operation.
8 Throttle Trigger
Controls the speed of the engine.
9 Left Handle
For holding the unit with the left
hand during operation.
10 Handlebar
For holding and controlling the unit
with both hands during operation.
11 Knob
Locks the handlebar in the selected
position.
12 Loop Handle
For transporting the unit.
13 Carrying Handle
For transporting the unit.
14 Deflector
Designed to reduce the risk of injury
from foreign objects flung
backwards toward the operator by
the attachment and from contact
with the attachment.
15 Gearbox
Transmits power from the engine to
the shaft.
16 Shaft
Holds the tools in position.
17 Hitch Pin
Secures the attachments and
simplifies removal and installation of
the attachments.
18 Fuel Tank
For fuel and oil mixture.
19 Fuel Filler Cap
For closing the fuel tank.
20 Manual Fuel Pump
Provides additional fuel feed for a
cold start.
21 Starter Grip
The grip of the pull starter, for
starting the engine.
22 Muffler with Spark Arresting Screen
Muffler reduces exhaust noises and
diverts exhaust gases away from
operator.
Spark arresting screen is designed
to reduce the risk of fire.
EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
Engine
Single cylinder two-stroke engine
Ignition System
Electronic magneto ignition
Specifications
A = 300 hours
B = 125 hours
C= 50hours
Displacement: 1.66 cu.in 27.2 cc
Bore: 1.34 in (34 mm)
Stroke: 1.18 in (30 mm)
Engine power to
ISO 8893: 1.1 bhp (0.8 kW)
Idle speed: 2,800 rpm
Max. engine speed: 8,900 rpm
Max. output shaft
speed (MultiTool
attachment): 200 rpm
Spark plug (resistor
type):
NGK CMR 6H
Electrode gap: 0.02 in (0.5 mm)
