MS 210, MS 210 C, MS 230, MS 230 C, MS 250, MS 250 C
English
43
If groove depth is less than specified:
N Replace the guide bar.
The drive link tangs will otherwise
scrape along the bottom of the groove –
the cutters and tie straps will not ride on
the bar rails.
The air filter system can be adapted to
suit different operating conditions by
installing a choice of filters. Changing
the filter is quick and simple.
The saw comes standard with either a
fabric filter or a fleece filter.
Fabric filter
For normal operating conditions and
winter operation.
Fleece filter
For dry and very dusty work areas.
If there is a noticeable loss of engine
power
N Press down the throttle trigger
lockout and move the Master
Control lever to choke closed l.
N Turn the knob 90° to the left.
N Lift off the carburetor box cover
vertically.
N Always replace damaged filters.
N Clean away loose dirt from around
the filter.
N Place fingers behind the air filter (1),
press thumbs against the housing
and swing the filter in direction of
rear handle.
Chain
type
Chain pitch Minimum
groove depth
Picco 1/4" P 0.16" (4.0 mm)
Rapid 1/4" 0.16" (4.0 mm)
Picco 3/8" P 0.20" (5.0 mm)
Rapid 3/8"; 0.325" 0.24" (6.0 mm)
Rapid 0.404" 0.28" (7.0 mm)
Air Filter System
Cleaning the Air Filter
