MS 210, MS 210 C, MS 230, MS 230 C, MS 250, MS 250 C
English
62
EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
CARB
The Emission Compliance Period used
on the CARB-Air Index Label indicates
the terms:
Engine
STIHL single cylinder two-stroke engine
MS 210, MS 210 C
MS 230, MS 230 C
MS 250, MS 250 C
Ignition System
Electronic magneto ignition
Fuel System
All position diaphragm carburetor with
integral fuel pump
Chain lubrication
Fully automatic, speed-controlled oil
pump with rotary piston
Weight
Specifications
A = 300 hours
B = 125 hours
C = 50 hours
Extended = 300 hours
Intermediate = 125 hours
Moderate = 50 hours
Displacement: 2.15 cu.in
(35.2 cm
3
)
Bore: 1.6 in. (40 mm)
Stroke: 1.1 in. (28 mm)
Engine power to
ISO 7293:
2.0 HP (1.5 kW)
at 9,000 rpm
Idle speed: 2,800 rpm
High speed setting
when performing
repairs (with bar and
chain): 12,500 rpm
Displacement: 2.45 cu.in
(40.2 cm
3
)
Bore: 1.6 in. (40 mm)
Stroke: 1.26 in (32 mm)
Engine power to
ISO 7293:
2.5 HP (1.9 kW)
at 10,000 rpm
Idle speed: 2,800 rpm
High speed setting
when performing
repairs (with bar and
chain): 14,000 rpm
Displacement: 2.77 cu.in
(45.4 cm
3
)
Bore: 1.7 in. (42.5 mm)
Stroke: 1.26 in. (32 mm)
Engine power to
ISO 7293:
3.0 HP (2.2 kW)
at 10,000 rpm
Idle speed: 2,800 rpm
High speed setting
when performing
repairs (with bar and
chain): 14,000 rpm
Spark plug (resistor
type): Bosch WSR 6 F
Electrode gap: 0.02 in. (0.5 mm)
Fuel tank capacity: 15.9 fl.oz (0.47 l)
Oil tank capacity: 6.8 fl.oz (0.2 l)
dry, without bar and chain
MS 210: 9.7 lbs
(4.4 kg)
MS 210 C with quick chain
adjuster and
Easy2Start:
10.6 lbs
(4.8 kg)
MS 230: 10.1 lbs
(4.6 kg)
MS 230 C with quick chain
adjuster and
Easy2Start:
10.8 lbs
(4.9 kg)
MS 250: 10.1 lbs
(4.6 kg)
MS 250 C with quick chain
adjuster and
Easy2Start:
10.8 lbs
(4.9 kg)
