Stihl MS 230 Service Manual

6 MS 210, MS 230, MS 250
3.5 Tightening Torques
DG screws are used in the polymer and light-alloy components. These screws form a permanent thread when
they are installed for the first time. They can be removed and installed as often as necessary without
detrimentally affecting the strength of the screwed assembly, providing the specified tightening torque is
observed. For this reason always use a torque wrench.
Fastener Thread
size
For component Torque Remarks
kpm Nm
Spline screw IS-M4x15 Cain brake cover 0.2 2.0
Spline screw IS-D4x15 Handle molding 0.16 1.6
Spline screw IS-P5x16 Connector (engine housing/oil pump) 0.4 4.0
Spline screw IS-M4x15 Ground wire (to cylinder) 0.35 3.5
Spline screw IS-DG5x24 Handle housing/front handle 0.35 3.5
Spline screw IS-DG5x24 Hand guard 0.35 3.5
Spline screw IS-DG5x24 Fan housing 0.35 3.5
Spline screw IS-DG5x24 Buffer (to front handle) 0.35 3.5
Spline screw IS-DG5x24 Buffer (to engine housing) 0.35 3.5
Spline screw IS-DG5x24 Ignition module (to engine housing) 0.4 4
Spline screw IS-DG5x24 Cylinder (to engine housing) 0.95 9.5
Collar screw DG 8x18 Guide bar mounting 1.6 16
M12x1 Carrier (clutch) 5.0 50
M14x1.25 Spark plug 2.5 25
Collar locknut M5 Muffler 0.8 8
Collar locknut M5 Filter housing/carburetor 0.27 2.7
Collar nut M8x1 Flywheel to crankshaft 2.8 28
M12x1.5 Decompression valve 1.4 14
Spline screw IS-DG5x16 Spiked bumper 0.37 3.7

Stihl MS 230 Specifications

General

Engine Power	2.0 kW
Displacement	40.2 cc
Weight	4.6 kg
Power Output	2.0 kW
Chain Pitch	3/8"
Powerhead Weight	4.6 kg
Bar Length	40 cm
Oil Capacity	200 cc
Bar Lengths Available	35 cm (14") / 40 cm (16")
