11MS 261, MS 261 C
3.3 Chain Lubrication
In the event of trouble with the
chain lubrication system, check and
rectify other sources of faults
before disassembling the oil pump.
.
Condition Cause Remedy
Chain receives no oil Oil inlet hole in guide bar is blocked Clean oil inlet hole
Intake hose or pickup body clogged
or intake hose ruptured
Fit new intake hose and pickup
body
Valve in oil tank blocked Clean or replace valve
Teeth on worm worn Install new worm
Oil pump damaged or worn Install new oil pump
Machine losing chain oil Oil pump damaged or worn Install new oil pump
Oil suction hose connection
damaged
Install new oil intake hose
Gasket between two halves of
crankcase faulty or crankcase
cracked
Install new gasket, inspect both
halves of crankcase and replace if
necessary
Oil pump delivers insufficient oil Oil pump damaged or worn Install new oil pump
Oil pump delivery rate set too low Adjust oil pump
(only on version with adjustable oil
pump)
Worm driver is loose Install new worm

Stihl MS 261 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Blade length	400 mm
Automatic oiling	Yes
Oil tank capacity	0.27 L
Fuel tank capacity	0.5 L
Engine displacement	50.2 cm³
Engine power	3.8 hp
Power source	Gasoline

Weight and Dimensions

Weight	5200 g
