Stihl MS 261 User Manual

86 MS 261, MS 261 C
: Push the handlebar (1) into its
seat (arrow) and hold it there.
: Insert and tighten down the
screws (1) firmly.
5902RA298 TG
1
5902RA351 TG
1
1
– Push the tank housing (2)
upwards and hold it there.
: Insert and tighten down the
screw (1) firmly.
– Reassemble all other parts in the
reverse sequence.
1
5902RA257 TG
2

Stihl MS 261 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Blade length	400 mm
Automatic oiling	Yes
Oil tank capacity	0.27 L
Fuel tank capacity	0.5 L
Engine displacement	50.2 cm³
Engine power	3.8 hp
Power source	Gasoline

Weight and Dimensions

Weight	5200 g
