MS 651
English
32
If the groove is not at least this deep:
N Replace guide bar
Otherwise the drive links will grind
against the base of the groove – the
bottoms of the cutters and the tie straps
will not lie against the bar.
N Turn the knob above the rear handle
in the direction of the arrow and
remove the carburetor box cover
N Remover filter
If there is a noticeable loss of engine
power:
N Wash the filter in STIHL special-
purpose cleaner (special
accessory) or a clean, non-
flammable cleaning liquid (e.g.,
warm soapy water) – rinse the filter
from inside to out under a water jet
– do not use high-pressure cleaners
N Dry all filter parts – do not expose to
extreme heat
N Do not oil the filter
N Reinstall filter
Picco 3/8“ P 5.0 mm
Rapid 3/8“; 0.325“ 6.0 mm
Rapid 0.404“ 7.0 mm
Remove Air Filter
Cleaning the Air Filter
