Stihl Operating instructions User Manual

FS 460 C-M, FS 460 C-M L
English
22
N Pull up the spool housing – turn
counterclockwise – approx. 1/6 turn
– until it engages – and then allow it
to spring back
N Pull the ends of the line outward
Repeat operation as needed until both
ends of the line are approx. 13 cm long.
A rotary movement from one click to the
next releases approx. 4 cm of line.
PolyCut Mowing Head
Proceed as described in the mowing
head information sheet.
Attaching grass cutting blades,
brush knives
With the grass cutting blade 255-8 (1),
the cutting edges must face clockwise.
Cutting attachments with 3 or
4 blades (2, 3) can face in any direction
– turn over these cutting attachments
periodically to avoid uneven wear.
N Use the guard ring for mowing tools
N Attach the deflector for metal
mowing tools
N Position cutting attachment (1)
N Fit the thrust washer (2) – curvature
faces upward
N Position thrust plate (3)
N Block the shaft
N Screw on the nut (4)
counterclockwise and tighten
Removing cutting attachments
N Block the shaft
N Unscrew the nut clockwise
Always switch off the engine to
load the mowing head by hand –
otherwise there is a risk of injury!
The collar (a) must engage the
hole (b) in the cutting attachment!
Remove the tool used to block the
shaft.
A nut that moves too easily should
be replaced.
2
3
1
4
002BA409 KN
b
a
