FS 460 C-M, FS 460 C-M L
English
34
N Fit the cap (1) on the shroud from
the rear and push the lug (2) into the
opening (3) in the shroud at the
same time.
N Swing the cap forwards onto the
shroud, insert and tighten down the
screw (4) firmly.
If engine running behavior is
unsatisfactory even though the air filter
is clean and the carburetor is properly
adjusted, the cause may be the muffler.
Have the muffler checked by a servicing
dealer for contamination
(carbonization).
STIHL recommends that you have
servicing and repair work carried out
exclusively by an authorized STIHL
servicing dealer.
Removing the rewind starter
N Take out the screws (1).
N Lift away the rewind starter.
Removing the rope rotor
N Use a screwdriver or suitable pliers
to remove the spring clip (2) from
the starter post.
N Carefully remove the E-clip (3).
4
3
2
9926BA022 KN
Engine Running Behavior Replacing the Starter Rope
and Rewind Spring
1 1
1 1
9926BA023 KN
3
2
9926BA024 KN
