► If 3 LEDs flash red: pull out the activation key,
remove the battery and consult a STIHL spe‐
cialist dealer.
There is a fault in the lawn mower.
► Release the locking button and control bar.
The blade stops turning after a short time.
► If the blade continues to turn: pull out the acti‐
vation key, remove the battery and consult a
STIHL specialist dealer.
The lawn mower is defective.
11.2 Checking the Blade
► Switch the lawn mower off, pull out the activa‐
tion key and remove the battery.
►
Upend the lawn mower, 16.1.
► Measure the following:
–
Thickness a
–
Width b
–
Sharpening angle c
► If the minimum thickness or minimum width is
fallen below: replace the blade, 20.2.
► If the sharpening angle is not correct: sharpen
the blade, 20.2.
► If anything is unclear: consult a STIHL special‐
ist dealer.
11.3 Testing the Battery
► Press button on battery.
The LEDs glow or flash.
► If the LEDs do not glow or flash: Do not use
the battery and contact your STIHL servicing
dealer.
There is a malfunction in the battery.
12 Operating the Lawn Mower
12.1 Holding and Guiding the Lawn
Mower
► Hold the handlebar with both hands so the
thumbs enclose the handlebar.
12.2 Setting the Cutting Height
Seven cutting heights can be set:
–
25 mm = position 1
–
30 mm = position 2
–
40 mm = position 3
–
50 mm = position 4
–
55 mm = position 5
–
65 mm = position 6
–
75 mm = position 7
The positions are indicated on the lawn mower.
Setting the cutting height
► Stop the engine.
The blade must not be turning.
► Pull lever (1) from the notch and move to the
desired position.
12 Operating the Lawn Mower English
0478-131-9962-C 33
