3 Overview
3 Star Knob Nut
Secures upper handle section to the lower handle
section.
4 Discharge Shield
Closes the discharge duct.
5Lever
Locks the handle adjuster.
6Lid
Covers the battery, ECO switch and activation key and
protects them from ingress of dust and dirt.
7Cover
Covers front axle and is used for carrying the mower.
8Blade
Mows and mulches grass.
9 Side Discharge Duct
Diverts grass cuttings sideways.
10 Side Chute
Discharges grass cuttings on lawn.
11 Side Discharge Shield
Closes the side discharge duct.
12 Lever
Adjusts cutting height.
13 Grass Box
Collects the grass cuttings.
14 Lockout Button
Switches the mower on and off in combination with the
switch lever.
15 Rear Discharge Duct
Diverts grass cuttings into the grass box.
16 Mulch Plug
Closes the rear discharge duct.
17 Deflector
Protects user from flying debris and contact with the
blade.
18 Battery
Supplies power to the mower.
19 Button
Activates the LEDs on the battery.
20 LEDs
Indicate battery’s state of charge and malfunctions.
21 Battery Compartment
Accommodates a spare battery.
22 Key Socket
Accommodates the activation key.
23 Activation Key
Activates the mower.
24 Battery Compartment
Accommodates the battery.
25 ECO Switch
Switches the ECO mode on and off.
# Rating label with serial number
3.2 Symbols
Meanings of symbols that may be on the mower and battery:
This symbol marks the activation key.
This symbol marks the key’s socket.
This symbol marks the ECO switch.
This symbol shows the weight of the mower.
ECO
XX
