Stihl TSA 230 - Main Parts

TSA 230
English
36
1 Battery Compartment
2 Water Nozzle
3 Spindle Lock
4 Abrasive Wheel
5 Water Attachment
6 Shut-off Valve
7 Guard
8 Front Thrust Washer
9 Front Handle
10 Trigger Switch
11 Trigger Switch Lockout
12 Rear Handle
13 Retaining Latch
14 Battery Locking Tabs
15 Battery
16 Push Button
17 Light Emitting Diodes (LED) on
Battery
18 Charger
19 Light Emitting Diode (LED) on
Charger
20 Power Supply Cord
# Serial Number
A Warning Label
B Warning Label
C Warning Label
Main Parts
16
15
13
12
11
10
6
B
14
9
5
3
2
1
20
19
18
8016BA032 KN
7
#
8
17
14
