Adjusting the fork distance (if
present)
– Raise the locking lever (1), or raise and ro-
tate the knob (2) by 180° depending on the
type of lock, (1) or (2), installed on the forks.
– Move the fork arms (3) in relation to the di-
mensions of the load to be lifted.
– Lock the forks in position again by moving
the lever (1) or knob (2) in the opposite di-
rection and ensuring that the forks are
locked in one of the notches on the fork car-
riage rail.
2000
1
3
2
Use
4
Moving the load
106 45758043484 EN - 11/2021 - 08
