– The clasp closes automatically to lock the
tiller.
CAUTION
Check that the tiller is locked correctly.
OptiSpeed tiller (only present on
EXV and EXVi versions)
The different work zones of the tiller depend-
ing on the tilt are explained below:
●
In zone (1), the brake is applied and the
truck cannot be moved.
●
In zone (2), the maximum authorised speed
varies according to the tilt of the tiller. The
reference (5) represents the curve of the
speed inside zone (2).
●
In zone (3), the truck can reach its maxi-
mum speed. The traction speed is propor-
tional to the angular position of the throttle.
In zone (4), the brake is applied and the truck
cannot be moved.
WARNING
During use, tilt the tiller and gradually change the
speed of the throttle in accordance with the above.
OM2282
1
2
5
3
4
Overview
3
Tiller
4745758043484 EN - 11/2021 - 08
