7. SERVICE
Please remove fiberglass car body completely off when servicing the base. When removing the
body to access the base you should follow the instructions below.
1. Turn off power, unscrew screws around skirt and remove the skirt
2. Open back door, disconnect ALL connectors at both sides . See instruction below
Disconnect the connector
at left side to separate
fiberglass and electrical
parts
Disconnect connector
at right side to
separate motor and
power
