GENERAL
Operating Voltage: 9.0VDC to 18VDC
Grounding system; Negative Ground
Max current consumption: 10A fused
DIMENSIONS
Radio Module:
178 mm x100 mm x 116 mm (W x H x D)
Display:
247.2 mm x 180.6 mm x 48.5 mm (W x H x D)
DISPLAY
10-inch Diagonal
16:9 aspect ratio
1024 x 600
Pixels: 1,843,200
Active area 222.72 (W) x 125.28 (H) mm
Operating Temperature (C) -20° to 70°
AUDIO
Peak power output: 50W x 4ch/4Ω
Load impedance: 4Ω nominal / 2Ω allowable
Continuous power output:
25W x 4ch/4Ω 20Hz to 20KHz,
1%THD at 14.4V
Audio output level (max): 4.0V preout
EQ: (15-band)
25Hz/40Hz/63Hz/100Hz/160Hz/250Hz/400Hz/
630Hz/1KHz/1.6KHz/2.5KHz/4KHz/6.3KHz/
10KHz/16KHz
Gain: ±12dB (2dB/step)
HPF: 25Hz/40Hz/63Hz/80Hz/100Hz/160Hz/250Hz
Slope: 6dB, 12dB, 18dB
AUDIO (CONT)
Subwoofer Preout
LPF:
25Hz/40Hz/63Hz/80Hz/100Hz/160Hz/250H
z
Slope: 6dB, 12dB, 18dB
Gain: -14dB to 7dB (1dB/step)
Phase: 0 or 180
Speaker level: ±9dB (1dB/step)
Time Alignment: 0 to 133 step (inch/ms)
USB
USB 2.0
Max current supply 1.5A
USB Class:
MSC (Mass Storage Class),
MTP (Media Transfer Protocol)
File system: FAT32, NTFS
BLUETOOTH
V4.2 dual
4dBm Class2
2.4GHz to 2.48GHz
FM TUNER
87.9MHz to 107.9MHz
Usable sensitive 0dB (mono S/N: 30dB)
SNR: 65dB
AM TUNER
530KHz to 1710KHz
Usable sensitive 0dB (mono S/N:20dB)
SNR 58dB
CAMERA(S) VIDEO INPUTS
NTSC OR PAL video formats
HDMI INPUT
Supported HDMI Resolutions:
640*480p, 720*480p, 1280*720p,
1920*1080i, 1920*1080p
TOSLINK (OPTICAL)
Output: 48khz Variable
BACKGROUND IMAGE (USER)
File Format: JPG / PNG
Resolution: 1024 x 600
File size is not limited
AUDIO/VIDEO FORMATS
AUDIO
MPEG-1 Audio Layer-3 (.mp3)
FLAC (.ac)
MPEG-2 Advanced Audio (.aac)
MPEG-4 Audio (.m4a)
Windows Audio (.wav)
OGG Audio (.ogg)
VIDEO
QuickTime (.mov)
MPEG-4 Video (.mp4)
Microsoft AVI (.avi)
MPG Video (.mpg)
MPEG Video 1/2 (.mpeg)
VOB DVD (.vob)
Flash Video (.v)
JPEG (.jpg)
CompuServe GIF (.gif)
PNG (.png)
JPEG (.jpeg)
Bitmap (.bmp)
SPECIFICATIONS SPECIFICATIONS
