- 57 -
Parts List
Item Part No. Description Qty.
32 28399-2 Base Motor Honda 1
32b 28193-2 Base Motor Electric 1
32c^ 28375-2 Base Motor Top B&S 1
32d^ 28376-2 Base Motor Bottom B&S 1
33 36081 Pig Tail 1 Phase 1
33b 36082 Pig Tail 3 Phase 1
34 36020 Starter Manual 1 Phase 1
34b 36068 Starter Manual 3 Phase 1
35 32179 Oil Seal Honda/B&S 2
35b 38507 Oil Seal 11.5 hp Robin
36 28398 Adapter Honda/11.5 hp Robin 1
36b 28202 Adapter B&S 1
37 27796 Bushing Clutch Adapter Honda/B&S/11.5 hp Robin 1
38 80100 Key Clutch Adapter Kohler/Electric 1
38b 27795 Key Clutch Adapter Honda/B&S/11.5 hp Robin 1
39 28844 Bushing Shaft Honda 1
39b 28267 Bushing Shaft B&S 1
40^ 28374 Spacer Motor Base B&S 4
41^ 22808 Kit Gas Tank B&S 1
42^ 46059 Cap Fuel B&S 1
43^ 34492 Clamp Hose B&S 2
44^ 46186 Hose B&S 18
45^ 80104 HHCS 1/2-13x1-1/4 B&S 4
46^ 80051 NUTNY 1/2-13 B&S 4
47^ 35321 Battery B&S 1
48^ 42672-2 Box Battery B&S 1
49^ 42673-2 Bracket Hold Down 18hp B&S 1
50^ 38114 Cable Battery 15 Blk 18hp B&S 1
51^ 48284 Cable Battery 25 Red 18hp B&S 1
52^ 47244 Rubber 1.5x6.75 B&S 3
53^ 34783 Throttle B&S 1
54^ 38121 Spring Governor 1
55^ 22075 Gearcase Assy (Incl 3-13, 15, 19, 21, 23 & 24, B, I - N) 1
1285PM /1650PM Gearcase Assembly
Note: + Use only Grade 2
* Seal with Silicone
^ Not Shown
To Next Page
