- 63 -
Parts List
Item Part No. Description Qty.
Spring Axle Assembly
1 32307 Tire/Rim Assy B78 x 13 2
2 34573 Dust Cap 2
3 32051 Bearing Cone 4
4 34501 Hub 4-bolt with tapered Bearing 2
5 32052 Seal Wheel Hub 2
6 21460-2 Axle 56 Spring 1
7 34972 Coil Spring 2
8 26971-2 Spring 2
9 26949-2 Bracket Spring 2
10^ 21490 Axle/Hub Assembly 1
Includes Items 2,3,4,5,6,B,C,D
A 80045 Lug Nut 1/2-20 8
B 80054 NUTSFX 3/4-16 SLTD ZN 2
C 80344 WSHR 3/4 SAE ZN 2
D 80316 PINCT 1/8x1-1/2 ZN 2
E 26195 U-Bolt 1/2-13 2
F 80051 NUTNY 1/2-13 14
G 80052 HHCS 1/2-13x6-1/2 ZN 2
I 80075 HHCS 1/2-13x1-1/2 ZN 8
Note: ^ Not Shown
