- 15 -
OPERATION
BEFORE STARTING
The 25CMP mixer is shipped completely assembled
and ready for operation.
TO PREVENT ANY ACCIDENTAL
STARTING, MAKE SURE THE
ELECTRIC CORD IS
DISCONNECTED
HARDWARE
Check all hardware on mixer before starting.
Consult the TORQUE CHART section of this
manual and tighten any loose hardware accordingly.
TT
TT
T
O STO ST
O STO ST
O ST
ARAR
ARAR
AR
T T
T T
T
THE ELECTRIC MOTHE ELECTRIC MO
THE ELECTRIC MOTHE ELECTRIC MO
THE ELECTRIC MO
TT
TT
T
OROR
OROR
OR
Use the proper size (3) wire (grounded)
extension cord, conforming to the Na-
tional Electric Code and Local Ordi-
nances. DO NOT use (2) wire extension
cords. Check any extension cord which
you plan on using carefully for broken
connectors, bare wires, or damaged
insulation. DO NOT use any cord found
to be in poor condition. Make sure the
extension cord is not routed through
standing water and that all connections
are tight. Use the shortest extension cord
possible.
Plug into any 115 single phase, 60-cycle,
fused outlet.
Turn motor on.
Check belt tension and tracking .
Total Drum 3.5 cu. ft.
Volume
Max Batch 2 cu. ft.
Size*
Before Starting/Hardware/Start
& Stop Electric Motor
TO STOP THE ELECTRIC MOTOR
Turn motor off.
Disconnect the power cord.
OPERATION
Start the motor as instructed.
With drum operating between 25-30 RPM, the mixer
is now ready for the addition of the concrete mix.
For best results proceed as follows:
1. Pour the required amount of water into
drum.
2. Add the required amount of gravel.
3. Add the required amount of cement.
4. Add the required amount of sand.
By adding the water and gravel first the drum will be
kept clean and a good tumbling action will be
maintained when cement and sand are added.
Discharge the mixer and immediately pour in the
required water for the next batch.
CAPACITIES
* Maximum batch size depends on mix and type of
aggregate used.
WARNING
