- 6 -
TECHNICAL DATA
25CMPT/25CMP/25CMPC Mixer – Specifications
Specifications
25CMPT
(Pedestal)
25CMP
(Wheelbarrow)
25CMPC
(Combination)
Operating Weight
(lbs.)
113 123 123
Batch Capacity
(bags)
¼ bag ¼ bag ¼ bag
Batch Capacity:
Total Volume of
empty drum
3.5 cu. ft. 3.5 cu. ft. 3.5 cu. ft.
Capacity: Concrete
Volume Total (wet)
2 cu. ft 2 cu. ft. 2 cu. ft.
L x W x H
---
Motor H.P.
1/3 Electric
6 amp
1/3 Electric
6 amp
1/3 Electric
6 amp
Motor RPM
1725 1725 1725
Voltage
115 115 115
Frequency (Hz)
60 60 60
Phase
Single Single Single
Drum RPM
31 31 31
V-Belt (4L Section)
Length
25" 28" 28"
Drum Diameter x
Opening
---
Drum Type
Polyethylene Drum Polyethylene Drum Polyethylene Drum
Structure
Pedestal Wheelbarrow Pedestal /
Wheelbarrow
Portability
Separates into 4-
pieces
Wheeled Frame Wheeled Frame
Separates into 4-
pieces
