- 13 -
1. TECHNICAL DATA
1. Power ON Indicator - Shows transmitter is on.
2. ON/Start Button - Starts machine/engine.
3. Stop Button - Stops machine/engine.
4. Right Side Forward/Reverse Button - Controls drum operation on the right side.
5. Left Side Forward/Reverse Button - Controls drum operation on the left side.
6. High/Low Speed Button - Controls machine speed high or low. Also shuts off vibration.
7. Vibe ON/Direction Button - Turns ON and controls direction of vibration.
1.6 REMOTE OPERATOR CONTROLS
2
5
6
7
4
3
1
