Stonex S850A GNSS Receiver – User Manual 3
Introduction
This document is user guide for S850A and it is intended to introduce how to
use the receiver correctly.
S850A GNSS receiver is a multiple-frequency receiver and designed for GNSS
surveying applications. It is available as a base station, or as a standalone
rover, which can be switched freely whenever and wherever, offering
maximum versatility in the system configuration to meet your specific
requirements. At the same time, S850A receiver can upgrade easily to
continually meet your new demand.
The integrated design of the receiver makes the S700A only 1.1 kg, which is
light and portable. The internal antenna supports all the satellite systems:
GPS, GLONASS, Galileo, Beidou, , QZSS, IRNSS. And users no longer have to
worry about upgrading RTK hardware to support other satellite systems.
The receiver is provided with electronic bubble so it’s possible to survey
corner points with inclined pole up to 30 degrees using the “point by 3
inclined measures” function.
An important feature inside S850A is Atlas reception: Atlas is a differential
corrections systems broadcasted on L-Band, allowing increase in position
accuracy in area not covered by conventional CORS working under Ntrip
Technology (lack of reference stations, lack of GPRS signals, etc). Atlas is
broadcasted by satellite systems, so the reception is nearly ensured all over
the world. Atlas uses similar technology compared to SBAS, but providing
better positioning accuracy.
Another important feature is the new modem GSM. Worldwide LTE,
UMTS/HSPA+ and GSM/GPRS/EDGE coverage Multi-constellation GNSS
receiver available for applications requiring fast and accurate fixes in any
environment. EG25-G is backward-compatible with existing EDGE and
GSM/GPRS networks, ensuring that it can be connected even in remote areas
devoid of 4G or 3G coverage.
