Parameter list software .112
U-- Relay contacts and lamps (password-protected)
Para-
meter
Description of function Setting range Default
value
U1
Function relay K1 0: no function (off)
1: compressor
2: defrosting circuit 1
3: evaporator fan
4: condenser fan
5: alarm
6: control contact circuit 2
7: defrosting circuit 2
8: relay function A (light 1)
9: relay function B (light 2)
10: relay function C (window heating)
11: relay function D (door frame heating)
12: relay function E (blade scraper)
13: relay function F
14: drip tray heating
15: buzzer
16: on if controller active
17: on if control circuit 1 active
18: on if control circuit 2 active
19: on if Set 1 active
20: on if Set 2 active
21: on if day mode active
22: on if night mode active
23: on if Superfrost active
24: Counter-heating during dehumidification
25: Humidify
1
U2
Function relay K2
see U1
2
U3
Function relay K3
see U1
3
U4
Function relay K4
see U1
5
U5
Function relay K5
see U1
0
U6
Function relay K6
see U1
0
U7
Function relay K7
see U1
0
U8
Function relay K8
see U1
0
U11
Function LED1 0: no function (off)
1: compressor/magnetic valve
2: defrosting control circuit 1
3: evaporator fan
4: condenser fan
5: alarm
6: control circuit 2
7: defrosting circuit 2
8: Light 1
9: Light 2
10: window heating
11: blade scraper
12: door frame heating
13: relay function F
14: drip tray heating
15: ”super-frost“
16: ”humidity”
17: control circuit 1 active
18: control circuit 2 active
19: set 1 active
20: set 2 active
21: day mode active
22: night mode active
23: display “MIN”
24: display “MAX”
1
