STORK TRONIC ST121-KD1KAR.112 - Parameter List: Control Circuit 2 (Y-); Circuit 2 Sensor and Setpoint Configuration

Order number: 900323.001 V1.74 Page 14
© Störk-Tronic 2021 • www.stoerk-tronic.com • Subject to modifications.
Parameter list software .112
Para-
meter
Description of function Setting range Default
value
U11
Function LED1 25: Display circuit 1 active
26: Display circuit 2 active
27: Controller active
28: Counter-heating during dehumidification
29: Humidify
U12
Function LED2
see U11
2
U13
Function LED3
see U11
3
U14
Function LED4
see U11
0
U15
Function LED5
see U11
0
U16
Function LED6
see U11
0
U17
Right decimal point
see U11
0
U20
Function LED week days 0: no function (off)
1: display weekday
2: see U21...U27
0
U21
Function LED7 (Mo)
see U11
0
U22
Function LED8 (Tu)
see U11
0
U23
Function LED9 (We)
see U11
0
U24
Function LED10 (Th)
see U11
0
U25
Function LED11 (Fr)
see U11
0
U26
Function LED12 (Sa)
see U11
0
U27
Function LED13 (Su)
see U11
0
U99
Password of parameter level U--
-99 ... 999 -19
Y-- Control circuit 2 (password protected)
Para-
meter
Description of function Setting range Default
value
Y0
Assignment of sensors to control circuit 2
detailed description of sensors in parameters H11
through H53
0: none
1: Sensor F1
2: Sensor F2
3: Sensor F3
4: Sensor F4
5: weighted mean value from F1 and F2
0
Y1
2nd control circuit: setpoint
Y 8. ...Y7
10,0
Y2
2nd control circuit: absolute setpoint or DeltaW 0: absolute
1: DeltaW
1
Y4
2nd control circuit: switching mode 0: heating
1: refrigerating
1
Y5
2nd control circuit: hysteresis 0.1...99.0°C 2,0
Y6
2nd control circuit: hysteresis mode 0: symmetrical
1: one-sided
1
Y7
Upper setpoint limit
Y8 ... +999°C
50,0
Y8
Lower setpoint limit
-99°C ... Y7
-50
Y9
Function in the case of sensor fault 0: contact off
1: contact on
1
Y10
Defrosting interval control circuit 2 0: no defrosting
1...99 hrs.
0
Y11
Defrosting time limitation thermostat 2 1...99 min. 30
Y99
Password of parameter level Y--
-99 ... 999 -19
