Parameter list software .112
N level (counters)
This level contains the parameters for counters. Parameters only accessible via the ST-Bus.
Para-
meter
Description of function Setting range
N0
Switching cycles of K1 (lower 16bit) ---
N1
Switching cycles of K1 (upper 16bit) ---
N2
Switching cycles of K2(lower 16bit) ---
N3
Switching cycles of K2 (upper 16bit) ---
N4
Switching cycles of K3 (lower 16bit) ---
N5
Switching cycles of K3 (upper 16bit) ---
N6
Switching cycles of K4 (lower 16bit) ---
N7
Switching cycles of K4 (upper 16bit) ---
N8
Switching cycles of K5 (lower 16bit) ---
N9
Switching cycles of K5 (upper 16bit) ---
N10
Switching cycles of K6 (lower 16bit) ---
N11
Switching cycles of K6 (upper 16bit) ---
N12
Switching cycles of K7 (lower 16bit) ---
N13
Switching cycles of K7 (upper 16bit) ---
N14
Switching cycles of K8 (lower 16bit) ---
N15
Switching cycles of K8 (upper 16bit) ---
N98
Deleting the relay switching cycles 0: -
1: reset
0
N99
Password of parameter level N -99 … 999 0
The number of switching cycles is calculated as follows (i.e. for K1): number = 65536 * N1 + N0. Parameter N98 resets the counters for
all relays. It depends on the setting of parameter L42. The return value is set back to “0” automatically.
T level (operating times)
This level contains the parameters for operating times. Parameters are only accessible via the ST-Bus.
Para-
meter
Description of function Setting range
T10
Total operating time (lower 16 bit) ---
T11
Total operating time (upper 16 bit) ---
T12
Operating time since last reset (lower 16 bit) ---
T13
Operating time since last reset (upper 16 bit) ---
T14
On-time relay "Compressor" (lower 16 bit) ---
T15
On-time relay "Compressor" (upper 16 bit) ---
T16
On-time relay "defrosting 1" (lower 16 bit) ---
T17
On-time relay "defrosting 1" (upper 16 bit) ---
T18
On-time relay "evaporator fan" (lower 16 bit) ---
T19
On-time relay "evaporator fan" (upper 16 bit) ---
T20
On-time relay "condenser fan" (lower 16 bit) ---
T21
On-time relay "condenser fan" (upper 16 bit) ---
T22
On-time relay "thermostat 2" (lower 16 bit) ---
T23
On-time relay "thermostat 2" (upper 16 bit) ---
T24
On-time relay "defrosting 2" (lower 16 bit) ---
T25
On-time relay "defrosting 2" (upper 16 bit) ---
T26
On-time relay "drip tray heating" (lower 16 bit) ---
T27
On-time relay "drip tray heating" (upper 16 bit) ---
T28
On-time relay function A: light 1 (lower 16 bit) ---
T29
On-time relay function A: light 1 (upper 16 bit) ---
