STORK TRONIC ST121-KD1KAR.112 - Parameter List: Control Circuit 1 (C-); Circuit 1 Sensor, Setpoint, and Mode

Order number: 900323.001 V1.74 Page 7
© Störk-Tronic 2021 • www.stoerk-tronic.com • Subject to modifications.
Parameter list software .112
Para-
meter
Description of function Setting range Default
value
b11
Function of external switching input E1 0: without function
1: controller on/standby
2: high-pressure alarm (see A20)
3: low-pressure alarm (see A25)
4: door contact (light on, fan off, see A13)
5: relay function A (light 1), not active in standby
6: relay function A (light 1), regardless of standby
7: relay function B (light 2), not active in standby
8: relay function B (light 2), regardless of standby
9: relay function C (window heating), not active in standby
10: relay function C (window heating), regardless of standby
11: relay function D (blade scraper), not active in standby
12: relay function D (blade scraper), regardless of standby
13: relay function E (door frame heating), not active in standby
14: relay function E (door frame heating), regardless of standby
15: relay function F, not active in standby
16: relay function F, regardless of standby
17: Set1 / Set2 change-over
18: day / night change-over
19: “super-frost“ on/off (see c21...c23)
20: evaporator fan on permanently
21: defrosting request circuit 1
22: defrosting request circuit 2
23: control circuit 1 on/off
24: control circuit 2 on/off
25: like 17 + remember state
26: like 5 + remember state
27: like 7 + remember state
0
b12
Switching input E1 inverse / not inverse 0: normal
1: inverse
0
b13
Function E2
see b11
0
b14
E2 inverse / not inverse
see b12
0
b15
Function E3
see b11
0
b16
E3 inverse / not inverse
see b12
0
b17
Function E4
see b11
0
b18
E4 inverse / not inverse
see b12
0
b99
Password parameter level b--
-99 ... 999 -19
c-- Control circuit 1
Para-
meter
Description of function Setting range Default
value
c0
Assignment of cold store sensors,
detailed description of sensors in parameters H11
through H53
0: none
1: Sensor F1
2: Sensor F2
3: Sensor F3
4: Sensor F4
5: weighted mean value from F1 and F2
1
c1
Setpoint for Set1
c8...c7
0.0
c2
Night setpoint
(relative to current setpoint c1 / c3)
-20 ... +20.0°C 5.0
c3
Setpoint for Set2
c8...c7
2.0
c4
Switching mode 0: heating
1: refrigerating
1
c5
Hysteresis 0.1...15.0°C 2.0
c6
Hysteresis mode 0: symmetrical
1: one-sided
1
