Assembling
1. Put the support back on its 4 spacers, with the vibration absorbers in place.
2. Fasten the support with the 4 screws, by using one of them to fasten the free ring terminal
of the cable connecting the support + hard disk setup to the chassis.
3. Check that the 4 lateral screws of the hard disk remain outside the chassis.
4. Put the cover and fastening brackets back in place.
5. Close it up using the 12 screws.
SNS - TECHNICAL NOTE
SECURE RETURN OPTION
Page 10/29 sns-en-secure_return_option_technical_note - 08/01/2022
