Data badge
Lower part of front frame.
Type of gas
This cooker must be used with either
Natural Gas only, or LP Gas only, as
stated on the appliance data badge.
Gas category
Natural Gas - I
2H, LP Gas - I3+
Pressure setting
G20 Natural Gas @ 20 mbar
G30 Butane @ 28-30 mbar
G31 Propane @ 37 mbar
Aeration
Fixed
Appliance class
Class 1, freestanding cooker
Electrical supply
230 - 240 V ~ 50 Hz
Warning: This cooker must be earthed.
Spark generators
Mains powered 8 outlet, controlled by
a single switch at the left of the fascia.
Gas hob
Burners have burner heads and caps
which are removable for cleaning.
Concealed electrodes to each burner
Electrical ratings
Grill 1775W
Fan Oven 1670W
Stir Fan 30W
Static Oven 2000W
Cooling fan 10W
Maximum load 5485W
Countries of destination
GB - Great Britain, IE - Ireland
20
Technical Data
Gas Hob Nominal Grammes per hour Injector
Type Burner Rate Qn Butane Propane size
Natural small x 2 1.0 kW - - 72 “X”
Gas medium x 4 2.0 kW - - 100 “Z”
large x 2 2.9 kW - - 1.1 “Y”
Total heat input ∑Qn 15.8kW - - -
LP Gas small x 2 1.0 kW 73 g/h 72 g/h 50
medium x 4 2.0 kW 145 g/h 143 g/h 70
large x 2 2.9 kW 211 g/h 207 g/h 85
Total heat input ∑Qn 15.8kW 1148 g/h 1130 g/h -
User’s Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 14
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Be Safe - Not Sorry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Storage Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Using the Minute Minder (if fitted) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Using the Hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using the Griddle (if supplied) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Using the Grill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Using the Ovens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installation Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 - 19
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Stoves Customer Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
1
Please keep this handbook for future reference, or for anyone else
who may use the appliance.
Contents
