Step 1: Prepare Installation
Important: ensure that you route all
mains and electrical cables and
flexible tubing well clear of any
adjacent heat source.
Ensure that all pipework is of the correct
rating for both size and temperature.
This cooker may be fitted flush to
base units.
Clearances
No shelf or overhang or cooker hood
shall be closer than a minimum of
650mm, but check with cooker hood
manufacturer’s recommendations.
The cooker must have a side clearance
above hob level of 90mm up to a
height of 400mm.
Moving the cooker
Do not attempt to move the cooker by
pulling on the doors or handles. Open
the door and grasp the frame of the
cooker, taking care that the door does
not shut on your fingers.
Take care to avoid damage to soft or
uneven floor coverings when moving
the appliance. Some cushioned vinyl
floor coverings may not be designed
to withstand sliding appliances without
marking or damage.
Appliance dimensions
All sizes are nominal, and some
variation is to be expected. The
‘depth’ of the cooker, as given below,
is to the front of the door and excluding
knobs and handles.
Width 1200mm
Depth 600mm
Height 900mm
26
