Method 1: Without housing unit
(between 2 base units)
Before installing the appliance, check
the internal dimensions as shown.
The space for the appliance must be
clear of obstruction. You may have to
cut into or remove any rear cross
members to obtain the 550 mm
minimum depth.
The fixing kit
is packed onto the oven
under the polystyrene packaging. You
will find 2 side trims (692 mm long)
and 4 runners (420 mm long). The
fixing screws are in a polythene bag
in the oven.
1. Remove the 6 screws (3 each side)
from the lower sides of the oven.
Take the 6 No 8 x 12 mm (silver)
self tapping screws from the
polythene bag, and use them to fit
one runner to each side of the
appliance.
2. Make sure they are the right way
up as shown.
3. Take one of the side trims, hold it
against the side of the base unit,
and mark off 692 mm from the
top edge of the base unit, to the
top edge of the runner.
Note: This ensures a 5 - 8 mm
clearance from the underside of the
worktop to the top of the appliance.
4. Measure 50 mm from the front
edge of the base units, to mark the
front edge of the runners.
5. Take 6 of the No 8 x 12 mm
(Black) chipboard screws and
screw the runners into opposition
the right way up as shown.
6. Fit the side trims to be flush to the
top and front edges of the base
units, using the remaining 6 No 8 x
12 mm (Black) chipboard screws.
25
INSTALLATION INSTRUCTIONS
23892 02 - Q721EF/720EF 03/04/2001 15:31 Page 27
