29
Method 3:
Housing unit with
internal height of 710 mm or more.
Note: You will not need the 4 runners
and 2 trims that are packed with the
oven for this installation.
(i) When installed in a typical 600
mm deep built in housing unit, the
false back should be removed
from the housing unit to provide
the necessary depth for installation.
(ii) When the false back is removed, it
is normally the case that the support
shelf for the appliance leaves a
gap between the back edge and
the wall of approximately 80 mm.
(iii) If no gap occurs between the back
edge of the shelf and the wall
behind the unit, we recommend
that a gap of at least 30 mm is
made by shortening the shelf.
Remove any fixings that may prevent
entry of the oven into the housing. The
cabinetry should be kept structurally
sound by fixing to adjacent cabinets,
floor or worktop.
