Remedying Faults in PP 1207–Klöckner Möller
Remedying faults PP 1207
page 48 –April 2005
A. Check limit switch (S4.2 ABB)(S10
KLM) and adjust limit switch cams and
replace if necessary
A. Adjust press time with potentiometer
(optimal time 26 seconds). With KLM
controls, time is adjusted by switch
8.2 Bales ready signal is triggered constantly
1. Bales ready -limit switch misaligned or
faulty
8.3 Bale weights not achieved (too light)
1. Limit switch cam not set correctly -
inadequate press time
