Streak 800Pro - Specification

8. Specification
Kit:
-Diagonal Wheelbase: 800mm
-Carbon Arm Boom Length: 281mm
-Carbon Arm Boom Weight: 23.6g
-Motor Mounting Frame Size: Φ13x22-34mm(Shaft x Screw Diagonal Distance)
-System Platform Frame Dimension: 105x66x42mm (LxWxH)
-Bipod Landing Gear Dimension:
188mm(Top Width) x 466mm(Lower Width) x 348mm(Height)
-Landing Skid Pipe: Φ10x420mm
-Bipod Landing Gear Weight: 136g
-Total Kit Weight: 1110g (Without Electronics & Props)
-Total Kit Weight With Motors & Props: 2330g
Propeller:
-Manufacturer: APC PROPELLERS in USA
-Size: 14×4.7 Inch
-Root Hole Diameter: 5-6mm
-Center hub thickness: 6mm
-Weight: 25.3g/pcs
Motor:
-Model: Alware Multicopter Brushless Motor 3515-15
-KV value: 400KV
-Stator Diameter: Φ35mm
-Stator Length: 15mm
-Propellwe Mount Diameter: 6mm
-Motor Dimension: Φ42.5x35mm
-Weight: 178g (with 3.5mm Bullet Connectors and Prop Mount)
-Input voltage: 22.2V 6S LiPo Battery
-Max continuous current: 35A(180sec)
-Max output power: 750W(180sec)
-Internal resistance: 175mOHM
-Recommended ESC: HobbyWing 40A/ 60A
