12 BA_310D-R_3100D-R_A16-3_180117_en
The cotton stand is mounted at the back on the right on the table plate after
assembly of the individual parts. (Fig. 1)
Check all screws at the frame for tight fit and retighten if necessary.
Mount the position transmitter and adjust corresponding to point “3.4.2
Positions of the machine“.
ATTENTION!
Prior to commissioning the machine it must be checked
whether the electric connection data on the type plate of the
motor, especially the network voltage and the frequency,
are according to the data of your current network.
All rust prevention agents, such as Vaseline or similar, must be carefully
removed from the sewing tools prior to commissioning the machine.
Fig. 2
