Strobel 310D-R - Threading and Thread Run (Fig. 7)

17 BA_310D-R_3100D-R_A16-3_180117_en
Fig. 6
4.3 Threading and thread run (Fig. 7)
CAUTION! Danger of injury!
Switch off the machine prior to threading and ensure the
machine is off by pressing the pedal for switching the
motor.
Fig. 7 shows the correct threading by using the thread sensor.
