3 Set-up and commissioning
3.1 Unpacking of the machine
Strobel machines are supplied either complete as upper part only.
The cotton stand and another machine accessories are located in the
packaging.
Prior to disposing of the packing material it must be carefully checked whether
all accessories parts have been unpacked.
3.2 Setting up the machine (Fig. 1 and Fig. 2)
CAUTION! Danger of injury!
Due to pulling in of parts of clothing or hair as well as
danger of crushing of fingers!
The machine must not be operated without a guard for the
belt for the upper part and for the motor.
The upper part of the table plate must be provided with bores according to the
drawing.
Frame and pedals as well as electrical connections must be mounted according
to the printed circuit.
Screw on the motor. The electric connection must be carried out according to
the printed circuit in the enclosed operating instructions for the motor.
Screw the upper part to the table plate. (Fig. 2)
The bolts (1) and the pressure spring (2) are enclosed with the machine
accessories and must be fitted as shown in Fig. 2.
The pedal rod system must be suspended according to Fig. 1.
Push on the knee lever and secure with knurled screw.
(Not necessary with pneumatic venting)
