16 BA_560_A4_180619_en
4.5
The plunger presses the material to be sewn towards the needle plate opening
to enable the needle to penetrate the fabric layers in the desired depth.
Stitch depth
4.5.1
Class 560-11 only
Setting the stitch depth
The adjusting knob for the stitch depth setting is situated on the left hand side
on the front side of the lower arm (Fig. 1).
1. Turning adjusting knob backwards (anticlockwise) results in the highest
plunger position and consequently in a deeper needle penetration.
2. When turning the adjusting knob to the front (clockwise) the plunger is
lowered and the needle penetrates the fabric less deep.
Per notch the stitch depth is altered by 0.04 mm.
4.5.2
Class 560-21 only
Setting the stitch depth
Refer for this to the operating instructions of the respective sewing drive.
