23 BA_560_A4_180619_en
Cl. 560-11, -21
Needle plate
Optional extra
6 mm opening
380.0270
Standard
8 mm opening
380.0271
Plunger
Standard Optional extra
181.0129 181.0130
for leather only
Material
under 300 gram 250 – 700 gram
Seam
