Strobel VEB100 Series Mechanic's Instructions

259.00.37
Pneumascher Schaltplan Kl. allg. mit pneum. Lüung
(Ea-DC1200/DC1210)
Pneumac circuit diagram cl. gen. with pneum. liing
(Ea DC1200/DC1210)
0 Z 1 Wartungseinheit Service unit
1 V 1 3/2-Magnetventil "Lüftung" 3/2-solenoid-way valve "lifting"
1 V 10 Drosselrückschlagventil "Lüftung" throttle non-return valve "lifting"
1 A 1 Zylinder "Lüftung" cylinder "lifting"
195.0513
0 Z 1
6bar
10bar max
1V1
A
P
R
1V10
1A1

Strobel VEB100 Series Specifications

General

Brand	Strobel
Model	VEB100 Series
Category	Sewing Machine
Language	English
