Strobel VEB100 Series Mechanic's Instructions

259.10.65
Pneumascher Bauschaltplan Kl. VEB100-1, -2, -2W, VEB200-1, -2
mit Nahtsicherung
Pneumac construcon circuit diagram cl. VEB100-1, -2, -2W, VEB200-1, -2 with seam lock
(Ea-DC12xx)
p
1
r
3
1V2
2 4
L2
L1
1V2
3
r
p
1
1V1
2B 4
L2
L1
1V1
A
B
293.0469 2 Schalldämpfer R 1/8 silencer R 1/8 293.0470 1 Doppelnippel R 1/8 nipple R 1/8 193.0473 2700 PA-Schlauch Ø6 PA hose Ø6 193.0478 3000 PA-Schlauch Ø8 PA hose Ø8 293.0772 3 Verschlußschraube R 1/8 lock screw R 1/8 293.0850 7 L-Einschraubanschluss R 1/8-6 L-threaded connection R 1/8-6 293.0853 2 L-Einschraubanschluss M5-4 L-threaded connection M5-4 293.0855 2 G-Steckanschluss 6-4 G-plug connection 6-4 293.0905 2 Y-Steckanschluss Ø6 Y-plug connection Ø6 293.0975 1 Wartungseinheit service unit 196.0716 2000 PA-Schlauch Ø4 PA hose Ø4 297.0170 1 Schnellverschlusskupplung Ø8 coupling Ø8 298.0077 1 Drosselrückschlagventil R 1/8 thrattle non-return valve R 1/8 298.0211 1 Miniatur-Zylinder miniature cylinder 298.0510 2 4/2-Wege Magnetventil 4/2-solenoid-way valve 298.0511 1 Eingangsmodul G1/8 links input module G1/8 left 298.0512 1 Eingangsmodul G1/8 rechts input module G1/8 right 298.0547 1 Miniaturzylinder miniature cylinder 298.0582 1 Kurzhubzylinder short stroke cylinder 298.0583 1 Kurzhubzylinder short stroke cylinder
Wartungseinheit
service unit
Magnetventil
solenoid valve
Lüftung
lifting
Transporteur
feed dog
Fadenbremse
thread brake
(293.0841)
(293.0850)
293.0975
293.0469
3x 293.0772
Beschriften
2x 298.0510
298.0511
298.0512
4x 293.0850
2x 293.0905
2x 293.0855
3x 293.0850
298.0077
293.0470
297.0170
293.0469
293.0853
298.0547
298.0211
293.0853
298.0852
298.0853
193.0478 3000 lg
O 8
193.0473 570 lg
O 6
193.0473 660 lg
O 6
193.0473 680 lg
O 6
196.0716 1000 lg
O 4
196.0716 980 lg
O 4
193.0473 720 lg
O
6
195.0516
