STROETER SC 750/5 - 2.14 Connection of brake motor and resistor

Standard user guide
V51-00-V19 eng
-24- Rights to changes reserved
2.14 Connection of brake motor and resistor
Important: Brake resistor is heated while system is running. Ensures free space to other components and
mount touch protection
.
3xAC
M
ϑ
L3
N
PE
L1
L2
PE
K1 K3
16
14
15
ϑ
K1
K4
Rectifier
