OPERATION OF COLOR BOOMERANG


THEOPTIONALCOLORBOOMERANGisequippedwithsixcolorlterholders.
Additionallterholders(51928000&51376000)canbesuppliedbyyourStrongdealer.
 TOOPERATE INDIVIDUAL COLOR FILTERS,lower thedesired lter selector
lever.Arockercatchlocatedinthecolordischousingholdsthelterinposition.
 TORELEASEACOLOR,pusheitherlterreleasearmupwardorengageanother
color,thusreleasingthepreviouscolorautomatically.
 NOTE:WHENPLACINGCOLORFILTERSintheboomerang,thelessdensecolors
(amber,pink)shouldbeplacedintheholderstowardtherearoftheboomerang(closertothearc),and
thoseofgreaterdensity(red,green)shouldbeplacedintheholderstowardthefrontoftheboomerang
(awayfromthearc).UseRoscoLux
®
(orequivalent)high temperaturelters.
 COLORTEMPERATUREREDUCTIONFILTERS,requiredforusewithtelevision
andvideotape,areavailablefromtheatricalsupplydealers.
 PROVISIONISMADEfor“stowing”colorholdersfortransport.Whenstowed,
thecolorholdersareprotectedfrombreakageorotherdamagecausedbymovingthespotlight.To
enableoperationofthecolorboomerang,detachthelowerthumbscrewsecuringthehingedportion
oftheboomeranghousingandfoldthepanelsupward.Thisallowsthecolorholderstodropintoa
“deployed”positionfornormaloperation.Anupperthumbscrewallowslockingthehingedpanels
intheupperposition.Toagainstowthecolorholdersfortransport,raiseallsixcolorholderstotheir
engagedposition,loosentheupperlockscrew,unfoldthehingedboomeranghousing,andsecurein
thelowerposition.
“Stowed”
“Deployed”
Housing
Lockscrew
Mounting
Thumbscrew
