PREFACE
 THESTRONGXENONSUPERTROUPER
®
isadirectcurrentfollowspotlight
systemcompletewithaxenonlamphouse,powersupply,opticalsystem,andaoorstandandyoke
assembly.Anoptionalsix-color,selfcancellingboomerang(OrderNo.7201188;seeFigure7)may
beorderedwithnewequipment,oritcanbeaddedatalaterdate.
 ONLY THE SPECIAL XENON POWER SUPPLIES manufactured by Strong
Internationalcanbeusedwiththexenonspotlight. Forinstallationandoperationofthepower
supply,seetheinstructionmanualfurnishedseparately.
 THEXENONLAMPHOUSEutilizesadeepellipsedichroicmetalreectordesignedto
operateinaxedpositionwithahorizontallymountedxenonbulbasthelightsource.Aheatlteris
locatedinthefrontofthelamphousetoreducetheheatattheopticalsystemandcolorboomerang.
 ONLY XENON BULBS designed for horizontal operation should be used in this
spotlight.Thelamphouseisdesignedforusewiththestandard2000watthorizontaltheatrebulb,
andanoptionalAdapterKit(OrderNo.7201192)allowsuseof1000and1600wattbulbs.Seethe
listinginthismanualfortheapprovedtypesandnecessaryadapters.
 ADJUSTMENTCONTROLforpositioningthexenonbulbislocatedattherearof
thelamphouse.Theadjustmentsareforthehorizontal,vertical,andfocuscontrolofthebulb.
 THE LAMPHOUSE INSTRUMENTPANEL isequippedwithanammeterand
runningtimemeter.Theammeterindicatestheoperatingcurrentofthelamp,andtherunningtime
meterrecordsthenumberofhoursthelamphasoperated.Thexenonbulbisignitedandextinguished
byuseoftheLAMPswitchmountedontheinstrumentpanel.

 THELAMPBLOWER,internallywiredinthelamp,operateson115V.ACandis
requiredtokeepthesealsonthebulbatasafeoperatingtemperature.Thisblowerwilloperate
continuouslyuntilpoweristurnedoffatthemainlineswitchtothexenonpowersupply.Anair
owswitchinthelamphousepreventsoperationofthexenonlampiftheblowerisnotoperating,or
ifairowisinadequate.Ifadditionalcoolingisrequired(i.e.50Hertzpowersource),anoptional
ExhaustBlowerAssembly(7201036;seeFigure8)maybemountedtothetopofthelamphouse.
 THELAMPHOUSEissuppliedwitha11foot(3.35m)cablecontainingthetwoDC
leads,thegroundlead,andallACcontrolleads.Thecableterminatesinamultiple-pinMSconnector
tomatetoacorrespondingreceptacleonthexenonpowersupply.
 WHENTRANSPORTINGthefollowspotlight,itisrecommendedthatthexenonbulb
beremovedfromthelamphouseandplacedinitsoriginalshippingcartonwiththeprotectivecover
onthebulbtopreventbreakage.
XST/001
