PARTS LIST
Figure2
Item PartNo. Description
1 39115000 FrontCasting
- 4198034  HolePlug,1/2"Chromed(notshown)
2 65122A00 HeatFilter,DichroicGlass
3 65933000 HeatFilterMountingBracket,WeldedAssembly
- 4110250  MountingScrew,10-24x1/4"FillisterHead
- 4107001  Lockwasher,#10
4 65156000 HeatShield,Right
- 65155000  HeatShield,Left
- 4080310  MountingScrew,8-32x5/16"PanHead
5 65114000 ReectorBulkheadCasting
- 4250752  MountingScrew,1/4-20x3/4"HexHead
- 4257000  SplitLockwasher,1/4"
- 4258001  Hexnut,1/4-20
6 65115000 AirDuctCasting
- 65171000  InsulatedBushing
- 65175000  InsulatorPlate
- 4081002  Screw,8-32x1"PanHead
- 4087004  Flatwasher,#8
7 23756000 DichroicReector,10"Diameter,Flanged
- 4250505  MountingScrew,1/4-20x1/2"SocketHead
- 4257004  Lockwasher,1/4"
8 65864000 IgniterAccessPanel
- 410050B  MountingScrew,10-32x1/2"PanHead
9 65503000 DCPulseIgniterAssembly
- 65858000  IgniterCase&CoilAssembly
- 65387000  MountingFoot(incl.with65858000)
- 4250250  Screw,1/4-20x1/4"NylonPanHead
- 25476000  IgniterPrintedCircuitBoardAssembly
10 65969000 LamphouseBaseAdapterAssembly
- 4250503  MountingScrew,1/4-20x1/2"HexHead
- 4257102  Flatwasher,1/4"
- 4257001  Lockwasher,1/4"
11 65966000 IgniterClamp&LeadAssembly
- 65131000  ContactClamp
- 4080870  ClampingScrew,8-32x7/8"SocketHead
12 7201029 RearCastingAssembly(seeFigure3)
13 65197000 SpacerWasher(2req’d.)
