Item PartNo. Description
14 65840000 BulbPositioningMechanism(seeDetailonPage32)
15 65968000 RearCoverPanelAssembly
- 65140000  CoverPlate
- 65166000  Plunger,BlackPlastic
- 65167000  Grommit,BlackPlastic
16 37985000 Thumbscrew
17 15010000 CompressionSpring
18 65150000 FenderWasher
19 65844000 ColletAssembly,2kW(incl.withItem14)
- 2148027  SnapRing(incl.withItem14)
20 7201037 LightShield,CircuitBoard
- 4060372  MountingScrew,6-32x3/8"PanHead
21 83131000 BlowerIntakeGrille
- 4080375  MountingScrew,8-32x3/8"PanHead
22 65865000 BasePan,WeldedAssembly
- 39215000  ArcStabilizationMagnet
- 65409000  “L”Bracket,Magnet
- 4110004  MagnetClamp
23 85109000 AirFlowSwitch(S2)
- 4040750  MountingScrew,4-40x3/4"PanHead
- 65158000  SwitchMountingBracket(incl.withItem24)
24 7201038 BlowerAssembly(B1),115V.AC,50/60Hz.
- 4080506  MountingScrew,8-32x1/2"PanHead
25 4110621 ActuatingScrew,CoverInterlockSwitch
- 4118001  Locknut,10-24
26 7201024 LamphouseTopCover,WeldedAssembly
- 4100502  MountingScrew,10-32x1/2"Tamperproof(HoltHead)
- 4107101  Flatwasher,#10
- 65149A00  Screwdriverfor4100502(HoltHead)
27 7201026 ExhaustCoverPlate(as shown;7201222withExhaustStack)
- 4100374  MountingScrew,10-32x3/8"PanHead
- 4108007  LockingHexnut,10-32
28 83747000 CathodeShockMountAssembly,2kW
- 4110750  MountingScrew,10-24x3/4"SocketHead
- 83748000  RingAssembly
- 83410000  CoilSpring,ShockMount
- 4100620  ClampingScrew,10-32x5/8"SocketHead
- 83364000  BaseMountBracket
29 65164000 ReectorTieRod(FactorySet-DoNotAdjust)
- 4258001  Hexnut,1/4-20
XST/030
PARTS LIST,Figure2(continued)
