Strong Super Trouper - Page 44

XST/042
FIGURE 7
Item PartNo. Description
1 7201058 BoomerangHousingAssembly
2 7201062 ColorArmPivotShaft
3 7200713 BearingBlock(2req’d.)
4 7201061 ColorArm(6req’d.)
5 7200911 Spacer(5req’d.)
6 51376000 ColorDiscCoverPlate(6req’d.)
- 1456000  BrassFastener(30req’d.)
7 7200905 ColorReleaseLever
8 7200930 ReleaseLeverPivotShaft
9 7158004 TorsionSpring
10 4151425 ThumbScrewKnob
11 4101501 Screw,10-32x1-1/2"SocketHead
7201110 COLOR BOOMERANG
ASSEMBLY (optional)
7201188 Kit includes 7201110
Boomerang plus (6) Color Gels
and (30) Fasteners
