Item PartNo. Description
12 4101000 Screw,10-32x1"SocketHead
13 3135012 Nutsert,10-32(2req’d.)
14 7156001 Spacer,3/8"Diameterx3/4"Long
15 4088008 AcornNut,10-32(3req’d.)
16 4198099 Standoff,1"Long(mountstoSpotlight;3req’d.)
17 4198096 HexSpacer,3/4"Thrd.10-32(earlymodels)
18 4107106 BoltRetainerPushNut
19 4100374 Screw,10-32x3/8"SocketHead
20 3135014 Nutsert,1/4-20
21 4258008 AcornNut,1/4-20
22 51396000 ColorArmCatchHook(6req’d.)
- 4080250  MountingScrew,8-32x1/4"PanHead(12req’d.)
23 51928000 ColorDiscSlideChannel(6req’d.)
24 51505000 RockerPad(2req’d.)
25 4100371 Screw,10-32x3/8"PanHead(securesSafetyCable)
26 4250508 Screw,1/4-20x1/2"PanHead(4req’d.)

  NOTSHOWN


7201220 SafetyCable
 3200337 Clip,SafetyCable(mountstoSpotlightBaseRail)
 3198643 CarabinerClip,SafetyCable
XST/043
PARTS LIST,Figure7(continued)
7201191 COUNTERWEIGHT
ASSEMBLY (optional)
Item PartNo. Description
1 4378001 Hexnut,3/8-16
2 4377003 Lockwasher,3/8"
3 2221120 ThreadedShaft
4 7200975 WeightPuck
