15
ILLUSTRATED PARTS BREAKDOWN [MODEL HVPFRB112 ONLY]
1
4
4
6
8
3
7
9
10
11
12
2
1 Bin, Acrylic 7 Mirror, End Panel
2 Box, Napkin 8 Bulb
3 Cup, Twist 9 Assembly, Rack Light
4 Panel, End 10 Rack, Wire
5
Assembly, Door Right Hand
(Left Hand opposite)
11 Support, Rear Rack
6 Bin, Trash 12 Bracket, Shelf
Note: Image
shown below is
for illustration
purposes only.
It may not reflect
your particular
case’s features
or options.
