• For more detailed information, see the section Technical data.
5 Installation
5.1 Unpack the machine
Note
We recommend that you keep all original packaging and fittings for future use.
1. Cut the packing tape on the top of the box.
2. Remove the loose parts.
3. Remove the unit from the box.
5.2 Check the packing list
Optional accessories may be included in the packing box.
The packing box contains the following items:
Pcs. Description
1 TransPol-5
1 Battery charger
1 Battery pack
1 Motor unit with reduction gear and 3 m connection cable
1 Straight handle with holder for flapper wheel
1 Right-angle handle with quick-coupling for rubber discs
4 Rubber discs
1 Spanner 20/24 mm (for right angle handle)
1 Spanner 10 mm (for straight handle)
1 Locking pin (for straight handle)
1 Shoulder strap
1 Instruction Manual set
Note
The reduction gear must always remain mounted on the motor.
5 Installation
TransPol-5 17
