Stretcher Operation
15
USING OPTIONAL INFLATABLE HEAD SUPPORT CUSHION
The optional inflatable head support cushion has two internal air blad-
ders. Squeeze the bulb (A) to inflate the bladders and provide more sta-
bility for the patient’s head. Press the release valve (B) to deflate the
bladders.
USING OPTIONAL WRIST RESTS
There are two optional wrist rests avail-
able for the 1069; standard and tempo-
ral .
To use the wrist rest, insert the support
tube (A) into the socket in the Fowler head
piece assembly. Turn knob (B) clockwise
to secure the wrist rest assembly.
To adjust the height of the wrist rest, turn
knob (C) counterclockwise to loosen it.
Raise or lower the wrist rest to the desired
height, and turn the knob clockwise to
tighten it and hold the wrist rest in place.
The ”U” shaped rest (D) can be pivoted up
and away from the patient when the wrist
rest is not in use.
USING OPTIONAL DRAPE SUPPORT/OXYGEN TUBING
The optional drape support/oxygen tubing provides an integrated drape support and
patient air delivery system. The oxygen tubing is inside the flexible support tube.
Place the mounting tab (A) in the I.V. receptacle at the head end of the
stretcher and insert the oxygen delivery line into the oxygen tube receptacle
(B). The assembly can be adjusted for maximum patient comfort.
A
B
A
B
B
B
A
1
2
C
C
A
D
D
